26.2.0

Released 3-Feb-2025

Release Notes

Analysis

26.2.0_BRI_link_elements_large_displacements

Greater control over link-elements in models with large displacements has been added. This new behavior applies to nonlinear static, direct-integration, and staged-construction load cases where the geometric nonlinearity parameter has been set to P-Delta plus Large Displacements.

Bridge Design and Rating

26.2.0_BRI_AASHTO_2024_Caltrans_amendments

2024 Caltrans amendments to AASHTO LRFD bridge design have been added.

26.2.0_BRI_IRC_112-2020_superstructure_design

IRC 112-2020 superstructure design of concrete bridges has been added, along with load combinations according to IRC 6-2017.

26.2.0_BRI_eurocode_superstruct_t-beams

Eurocode superstructure design of concrete T-beam bridges has been added.

Documentation

26.2.0_BRI_analysis_reference_manual

The CSI Analysis Reference Manual has been updated to include content for minor existing features that were previously only described in the Help, as well as for style and improved ability to search within the PDF file.

26.1.0

Released 25-Oct-2024

Release Notes

Bridge Modeler

26.1.0_BRI_spiral_layout_line

Bridge layout lines can now include a highway curve with unequal spirals or individual spiral segments.

Bridge Design and Rating

26.1.0_BRI_comprehensive_col_calcs

Comprehensive calculation reports for Eurocode substructure column strength checks are now available.

26.0.0

Released 5-Sep-2024

Release Notes

Structural Model

26.0.0_BRI_sumitomo_damper

A new link property Sumitomo Viscoelastic Damper has been added to represent high-damping rubber vibration control damper devices produced by Sumitomo Rubber Industries.

Bridge Modeler

26.0.0_BRI_concrete_void_slab_deck

A concrete voided slab bridge deck section has been added.

26.0.0_BRI_pier_assign_wall_bents

Pile pier and shaft pier foundations can now be assigned to wall bents.

Bridge Design and Rating

26.0.0_BRI_AS_5100.5:2017_superstruct

AS 5100.5:2017 bridge superstructure design of precast concrete I-girder, U-girder, box-girder, and Super-T bridge sections has been added.

26.0.0_CAN/CSA_S6-19_superstruct

CAN/CSA S6-19 bridge superstructure design and rating has been added.

26.0.0_BRI_strength_substruct_bent_col

Strength design of substructure (bent) columns has been added according to Eurocode 2-2004, including design results display.

Output and Display

26.0.0_BRI_color_contours

Frame force/moment diagrams can now be displayed with colored contours.

26.0.0_BRI_api_.NET8

The CSiBridge API has been updated to support .NET 8.

25.3.0 | 25.3.1

Released 11-Jul-2024

Release Notes

Loading

25.3.0_BRI_AASHTO-2020_wind_loading

Automated bridge wind loading according to AASHTO 2020 9th Edition has been added.

Bridge Design and Rating

25.3.0_BRI_IRC-112_column_service_check_calc

Comprehensive calculation reports for IRC-112 column service checks have been added.

25.2.0

Released 29-Mar-2024

Release Notes

Bridge Modeler

25.2.0_BRI_two-way_sloping_deck

The ability to model two-way sloping (crowned) bridge decks is now available.

Bridge Design and Rating

25.2.0_BRI_NZTA_BM3.4_load_combo

New Zealand NZTA automated bridge design load combinations have been updated according to the latest NZTA BM 3.4 code.

25.2.0_BRI_NZTA_BM3.4_superstruct

Superstructure design and corresponding comprehensive calculation reports according to New Zealand NZTA BM 3.4 are now available for precast I, precast U, precast box, and super-T girders with composite slab.

25.2.0_BRI_IRC_112-2020_service_crack

Service cracking check of bent columns according to IRC 112-2020 has been added.

25.2.0_BRI_AASHTO_non-comp_calc_reports

Comprehensive calculation reports for AASHTO non-composite steel I-girder strength and service rating requests have been added.

25.1.0

Released 1-Dec-2023

Release Notes

Introduction

25.1.0_BRI_enhancement_video

Learn more about the latest enhancements in CSiBridge 25.1.0.

Bridge Modeler

25.1.0_BRI_flange_stiffeners_U_girder

Bottom-flange longitudinal stiffeners can now be specified for steel U-girder bridges using the steel beam editor. The stiffeners are accounted for in analysis as well as superstructure strength design and rating requests. Layout options include the longitudinal start and end position, transverse ratios, orientation and insertion-point location.

Bridge Design and Rating

25.1.0_BRI_AASHTO_box_girder_superstruct

Superstructure design is now available for precast box girder bridges according to the AASHTO code.

25.1.0_BRI_eurocode_calcs_report_multicell

Comprehensive calculation reports are now available for superstructure design of multi-cell concrete box-girder bridges according to Eurocode. These provide detailed calculations and diagrams for the flexural demands and flexural resistance for each individual girder.

Output and Display

25.1.0_BRI_speed_recovering_results

Performance improvements have been made to increase speed and reduce memory usage when recovering results.

Cloud Sign-in Licensing

25.1.0_BRI_cloud_sign_in_lic

Cloud Sign-in licensing is now available

  1. • Access CSI software using secure user credentials — no more activation keys
  2. • Access licenses anywhere with internet access
  3. • Option to create License Groups to manage who has access to your licenses
  4. • Option to remotely terminate an active license session
  5. • Option to federate your identity provider (IdP), allowing users to use their familiar company credentials instead

Cloud Sign-in Licensing Details

25.0.0

Released 7-Jul-2023

Release Notes

Introduction

25.0.0_BRI_enhancement_video

Learn more about the latest enhancements in CSiBridge v25.0.0.

Bridge Modeler

25.0.0_BRI_wall_piers_defined_bridge_modeler

Wall piers can now be defined and included within a bridge model.

25.0.0_BRI_precast_box_deck_section

A precast-concrete box-girder bridge section has been added. Girders can be in contact or separated. Grouting conditions can be considered, with control available in staged construction.

25.0.0_BRI_circular_layout_lines

Layout lines can now include circular segment types.

Bridge Design and Rating

25.0.0_BRI_strength_design_IRC-112-2020

Strength design of bent columns according to IRC 112-2020 has been added.

25.0.0_BRI_service_cracking_check_AASHTO_LRFD_2020

Service cracking check of bent columns according to AASHTO LRFD 2020 has been added.

25.0.0_BRI_CA_amends_AASHTO_LRFD

California amendments to the AASHTO LRFD Bridge Design Specification – 8th Edition have been added for steel and concrete bridge design and rating.

Structural Model

25.0.0_BRI_frame_hinge_assign_presets

Frame hinge assignment presets, including distributed plasticity are now available.

Data Files

25.0.0_BRI_JTJ/T-483-2020_chinese_mat

JGJ/T 483-2020 high-strength steel materials have been added to the Chinese material library.

Database Tables

25.0.0_BRI_detailed_data_single_row

Detailed data for a single database table row is now available.

Application Programming Interface (API)

25.0.0_BRI_api_access_to_bridge_modeler_object

A new API has been added that provides access to the bridge modeler and bridge object functionality.

24.2.0

Released 15-Feb-2023

Release Notes

Bridge Design and Rating

24.2.0_BRI_design_calcs_JTG-3362-2018

Comprehensive design calculation reports have been added for Chinese JTG 3362-2018 bridge superstructure design checks for shear, torsion, and combined shear and torsion.

Loading

24.2.0_BRI_temp_loads_rail_tracks

Temperature loads can now be applied to rail tracks. Loads can vary along the length of the track. Nonlinear analysis can capture slippage at the track supports, and linear or nonlinear buckling of the track under temperature loading can be analyzed.

24.2.0_BRI_temp_loads_tendons

Temperature loads applied to bridge objects are now automatically applied to their tendons when the tendons are modeled as elements.

Bridge Modeler

24.2.0_BRI_layout_lines_circles

Simple circles have been added to the definition of bridge layout lines for cases where highway spirals are not needed.

24.1.0

Released 12-Oct-2022

Release Notes

Bridge Design and Rating

24.1.0_BRI_AASHTO_LRFD_2020_substructure_columns

The strength design of substructure (bent) columns has been added according to the AASHTO LRFD 2020 code. Design is controlled by defining one or more Design Requests which can specify a set of load combinations, bent columns, column stations, and other parameters to be considered. Results for each Design Request are provided in the form of an Excel spreadsheet that can be used for further calculations and for inclusion in reports. Design results are also available in database tables for display, export, and reporting.

Structural Model

24.1.0_BRI_property_libraries

New and updated property libraries:
  • • New Indian frame-property library for steel sections
  • • Updated Chinese frame-property library
  • • New Canadian material-property library

Loading

24.1.0_BRI_vehicle_library_NZ

New Zealand vehicle library has been updated.

Output and Display

24.1.0_BRI_database_tables_secondary_prestress_forces

New database tables "Bridge Object Forces with Tendons" and "Bridge Object Girder Forces with Tendons", providing the secondary prestress forces on the full bridge section and the individual bridge girders

24.1.0_BRI_display_NL_hinger_state

Improved display of nonlinear hinge states and statuses.

Application Programming Interface (API)

24.1.0_BRI_API_multi_instances_plugins_speed

The Application Programming Interface (API) now offers more control for connecting to multiple instances of CSiBridge, a new interface to simplify the development of plugins, and speed enhancements for external .NET clients.

24.0.0

Released 11-Mar-2022

Release Notes

Bridge Modeler

24.0.0_BRI_bridge_tendons_def

Bridge tendon layout can now be parametrically defined directly with respect to any girder as well as the bridge layout line.

24.0.0_BRI_live_load_continuous_pours

Modeling of closure pours at double-bearing bents for concrete precast I-girder and Super-T girder bridges is now available. This can be used to simulate a live-load continuous superstructure or full integral continuity with the substructure.

Bridge Design and Rating

24.0.0_BRI_AASHTO_LRFD_2020_superstructure

Bridge superstructure design according to the AASHTO LRFD 2020 code has been added. This new code is also available as a resistance code for superstructure rating.

24.0.0_BRI_longitudinal_web_stiffeners

Longitudinal web stiffeners for steel I-girders and steel U-girders can now be modeled on a girder-by-girder basis. These stiffeners are carried through modeling, analysis, design and rating.

Design

24.0.0_BRI_euro_shell_design

Concrete shell design per Eurocode 1992-1-1:2004 has been enhanced, including the ability to set design preferences and national annexes, improved iteration for determining the optimum amount of reinforcement, handling of variable-thickness shells, and the presentation of detailed results in tabular form.

Analysis

24.0.0_BRI_AS3600-2018_time_dep_mat

Time-dependent behavior of concrete has been added for the AS3600-2018 code, including creep, shrinkage, and age-dependent stiffness.

24.0.0_BRI_disable_bending_channel

The ability to enable/disabled the coupling between major bending, shear V2, and torsion is now available for channel and general sections.

23.3.0 | 23.3.1

Released 24-Sep-2021

Release Notes

Loading

23.3.0_BRI_aashto_vehicles

New vehicles have been added to the AASHTO Rating and Caltrans libraries.

Design

23.3.0_BRI_aashto_2020_steelFrames

Steel frame design according to the AASHTO 2020 LRFD code has been added.

Output and Display

23.3.0_BRI_response_recovery

Moving load response recovery has been sped up by means of multi-threading for database tables and the bridge object response display.

23.3.0_BRI_superstructure_calcs

Superstructure design calculation reports are now available for multicell concrete box and concrete T-beam bridges according to the IRC code.

23.2.0

Released 19-May-2021

Release Notes

Modeling

23.2.0_BRI_pour_concrete

Staged-construction operations Pour Concrete and Remove Forms are now available for Super-T bridge sections. Using these operations, the weight of the wet concrete slab can be applied to the girders in one stage, and the stiffness of the cured slab activated in a subsequent stage.

Loading

23.2.0_BRI_RSF_JTG/T

The response-spectrum function according to the Chinese JTG/T 2231-01-2020 code has been added.

Analysis

23.2.0_BRI_proformance_improvements

Performance has been improved for models with frame elements in the presence of many load patterns. This includes speed increases in stiffness formation, event determination, and state-update operations. Nonlinear static, staged-construction, and nonlinear direct-integration time-history load cases will benefit the most.

23.2.0_BRI_joint_reaction_response

Speed improvements have been made for calculating joint-reaction response for influence-based moving-load cases.

23.1.0

Released 15-Mar-2021

Release Notes

Application Programming Interface (API)

CSiBridge v23.1.0 Enhancements Application Programming Interface (API)

Improved performance and examples for remote API and COM clients.

Loading

CSiBridge v23.1.0 Enhancements Loading

Temperature gradient loading has been added according to the IRC:6-2017 code.

CSiBridge v23.1.0 Enhancements Loading 1

Automatic bridge wind loading has been added according to the IRC:6-2017 code.

CSiBridge v23.1.0 Enhancements Loading 2

The IRC vehicle library has been expanded to include the Special Vehicle (SV), Fatigue Truck (40T), and 70R Tracked vehicle per the IRC:6-2017 code.

23.0.0

Released 25-Jan-2021

Release Notes

23.0.0_BRI_enhancement_video

Learn more about the latest enhancements in CSiBridge v23.0.0.

Analysis

CSiBridge v23.0.0 Enhancements Analysis

Speed improvements to moving load analysis on spine models containing many influence points.

CSiBridge v23.0.0 Enhancements Analysis 1

Speed improvements nonlinear static, nonlinear multi-step static, and nonlinear direct-integration time-history cases using the advanced or multi-threaded solvers.

Design

CSiBridge v23.0.0 Enhancements Bridge Design & Rating

Precast Super-T girder design has been implemented according to the NZTA Bridge Manual.

Modeling

CSiBridge v23.0.0 Enhancements Bridge Modeler

Layout lines can now be defined using point-of-intersection data.

CSiBridge v23.0.0 Enhancements Bridge Modeler 1

New Super-T girder and bridge-section definitions have been added, including detailed tendon layout.

CSiBridge v23.0.0 Enhancements Bridge Modeler 2

Job scripting has been added to allow automating several analysis, design and reporting actions into a single command in order to expedite iterative tasks.

User Interface

CSiBridge v23.0.0 Enhancements Application Programming Interface (API)

Database tables can now be accessed via the API for both editing and display purposes.

Cloud Licensing

CSiBridge v23.0.0 Enhancements Cloud Licensing

Cloud-based licensing is now standard for CSiBridge.

  1. • Cloud-based server requires no setup
  2. • Access licenses outside of company networks and VPNs
  3. • Share licenses between users (non-simultaneous)
  4. • Check-out a license to work offline
Cloud FAQ

22.2.0

Released 20-Oct-2020

Release Notes

Loading

CSiBridge Enhancements 22.2.0 Loading

Korean vehicle library available

Design

CSiBridge 22.2.0 Enhancements Bridge Design & Rating

Detailed design-calculation reports for Concrete T-beam bridge sections per AASHTO LRFD

CSiBridge Enhancements 22.2.0 Design & Rating

AASHTO steel I and U-girder vertical position of longitudinal stiffeners for service and constructability checks

CSiBridge 22.2.0 Enhancements Bridge Design & Rating 1

Detailed design-calculation reports for Steel I-girder bridge sections per CAN/CSA-S6

Analysis

CSiBridge 22.2.0 Enhancements Analysis

Improved handling of equilibrium unbalances and additional controls for non-iterative event-to-event analyses

CSiBridge Enhancements 22.2.0 Analysis

  • Speed improvements for nonlinear cases with multi-threaded solver
  • Speed improvements in the recovery of analysis results

Database Tables

CSiBridge 22.2.0 Enhancements Database Tables

Automatic tabular output to multiple files

22.1.0

Released 6-Jun-2020

Release Notes

Output and Display

CSiBridge 22.1.0 Enhancements Graphics

Enhancements made to 2D graphics in DirectX now generate clearer views much faster

CSiBridge 22.1.0 Enhancements Graphics 1

Recovery of nonlinear static and direct-integration results has been optimized

Design

CSiBridge Enhancements 22.1.0 Design & Rating

Non-zero tension limits for concrete slabs can now be specified for the service checks of steel I-girder and U-girder bridges

CSiBridge 22.1.0 Enhancements Bridge Design & Rating

Chinese concrete box-girder bridge design has been updated and enhanced to the JTG 3362-2018 code from the 2004 version

CSiBridge 22.1.0 Enhancements Bridge Design & Rating 1

Consideration of rebar development length in superstructure design/rating now available per AASHTO LRFD, CAN/CSA-S6, and EUROCODE codes

Modeling

CSiBridge 22.1.0 Enhancements Modeling

Bridge-rail interaction modeling is now available, including nonlinear supports representing ballast and clips. Support properties can vary under vehicle load.

CSiBridge 22.1.0 Enhancements Modeling 1

Steel U-girder section editor is now available for easier definition of plate sizes and vertical web stiffeners.

CSiBridge 22.1.0 Enhancements Modeling 2

Nonlinear shell analysis is now possible for metals using von Mises (J2) plasticity in layered shells.

User Interface

CSiBridge 22.1.0 Enhancements Application Programming Interface (API)

The API can now start and control instances of SAP2000 on remote computers, including the retrieval of results. This enables distributed processing for running large suites of Performance-based Design histories, extensive parameter studies, and Monte Carlo simulations.

Loading

CSiBridge 22.1.0 Enhancements Loading

Auto wind loads on area objects can now be distributed to adjoining frames

22.0.0

Released 15-Jan-2020

Release Notes

Parametric Bridge Modeling

CSiBridge 22.0.0 Enhancements Bridge Modeler

Web- and flange-plate layouts can be printed for steel I-girder bridges, including comprehensive dimensions and steel-weight quantities. The location of stiffeners and diaphragms that define the shear panels are shown on the drawings. The number of spans shown per sheet can be customized.

Structural Components

CSiBridge 22.0.0 Enhancements Structural Model

Parametrically defined detailed foundations, including soil springs, can now be added to a model

Analysis

CSiBridge 22.0.0 Enhancements Analysis

Load cases within a single model can now be run in parallel using multiple machines and combined on a single machine

21.2.0

Released 15-Nov-2019

Release Notes

Design

CSiBridge 21.2.0 Enhancements Bridge Design & Rating

Concrete box girder bridge design request to determine required tendon area to satisfy stresses under permanent and service load conditions is now available

CSiBridge 21.2.0 Enhancements Bridge Design & Rating 1

Steel frame rating has been added for axial demands and user specified resistances

Output and Display

CSiBridge 21.2.0 Enhancements Results Display & Output

Load combination results are now available on a step-by-step basis for linear load combinations containing one or more stepped load cases

CSiBridge 21.2.0 Enhancements Results Display & Output 1

Nonlinear energy component output is now available per group for nonlinear load cases

Parametric Bridge Modeling

CSiBridge 21.2.0 Enhancements Bridge Modeler

Ability to specify steel I-girder plate sizes and web stiffeners prior to running analysis, design, or rating

Analysis

CSiBridge 21.2.0 Enhancements Analysis

Analysis errors, warnings, and informational messages are now stored and shown after the analysis completes, as well as accessible via database tables

21.1.0

Released 22-Aug-2019

Release Notes

Output and Display

CSiBridge 21.1.0 Enhancements Efficiency

Faster display of results from modal time-history load cases, including FNA, for large models with many modes.

Design

CSiBridge 21.1.0 Enhancements Bridge Design

  • Concrete superstructure design according to the Indian IRC-2011 code for flat slab and T-beam bridge sections
  • Concrete superstructure design according to the Indian IRC-2011 code now calculates the required reinforcement quantity.

CSiBridge 21.1.0 Enhancements Bridge Design 1

  • Detailed reports for CAN/CSA S6 steel I-girder bridge strength design requests
  • Detailed reports for AASHTO steel U-girder bridge strength and service design and rating requests

Analysis

CSiBridge 21.1.0 Enhancements Analysis

Analysis can now run multiple load cases in parallel. This is particularly efficient for considering large suites of earthquakes in Performance-Based Design.

Parametric Bridge Modeling

CSiBridge 21.1.0 Enhancements Bridge Modeler

Quick bridge template enhanced to remember previous settings and provide additional options when creating a new bridge model

CSiBridge 21.1.0 Enhancements Bridge Modeler 1

Bridge modeler can now generate multiple pairs of braces for steel cross-frames

CSiBridge 21.1.0 Enhancements Bridge Modeler 2

Bridge modeler now allows detailed definition of foundations at the bottom of bent columns, including soil springs

21.0.0 | 21.0.1|21.0.2

Released 19-Feb-2019

Release Notes

20.2.0

Released 19-Sep-2018

Release Notes

Analysis

CSiBridge 20.2.0 Enhancements Analysis



Modeling

CSiBridge 20.2.0 Enhancements Modeling

Automated prestress tendon generation based on tendon layouts defined in precast I-girder frame section properties

Parametric Bridge Modeling

CSiBridge 20.2.0 Enhancements Bridge Modeler

The quick bridge template has been expanded to allow defining a more complete model, including substructure, superstructure, loading, and design criteria

CSiBridge 20.2.0 Enhancements Bridge Modeler 1

Bridge deck section superstructure loads provide the ability to easily model barrier, median, sidewalk, haunch, construction, and wearing surface loads

CSiBridge 20.2.0 Enhancements Bridge Modeler 2

User specified diaphragm depths can now be specified for precast I-girder and concrete tee bridges

Design

CSiBridge 20.2.0 Enhancements Bridge Design

Bridge superstructure design has been added according to the AASHTO LRFD 2017 8th Edition code

CSiBridge 20.2.0 Enhancements Bridge Design 1

Load rating of steel U-girder composite bridges has been added according to the AASHTO Manual for Bridge Evaluation 2nd Edition

CSiBridge 20.2.0 Enhancements Bridge Design 2

Load rating of steel U-girder composite bridges has been added according to the CAN/CSA-S6-14 code

20.1.0

Released 4-May-2018

Release Notes

Design

CSiBridge 20.1.0 Enhancements Bridge Design

Load rating of concrete box girders, precast I and U-girders, and steel composite I-girders has been added according to the CAN/CSA-S6-14 code

CSiBridge 20.1.0 Enhancements Bridge Design 1

Design of steel composite I-girders has been added according to the BS 5400 code

Analysis

CSiBridge 20.1.0 Enhancements Analysis

Linear time-history analysis can now be performed in the frequency domain allowing the consideration of frequency-dependent properties, sub-systems, and/or boundary conditions

Parametric Bridge Modeling

CSiBridge 20.1.0 Enhancements Bridge Modeler

User-defined concrete box-girder sections can now be updated as area or solid models for analysis and superstructure design and rating

Output and Display

CSiBridge 20.1.0 Enhancements Results Display & Output

Detailed calculation reports for AASHTO steel I-girder rating have been added

CSiBridge 20.1.0 Enhancements Results Display & Output 1

Strain results are now available for shell and solid objects

Import and Export

CSiBridge 20.1.0 Enhancements External Import/Export

Area objects in a specified X-Y plane can now be exported to SAFE for further analysis, design, and detailing

20.0.0

Released 18-Dec-2017

Release Notes

Modeling

CSiBridge 20.0.0 Enhancements Modeling

An option has been added to control the limiting negative stiffness ratio for frame hinges.

Design

CSiBridge 20.0.0 Enhancements Bridge Design

Bridge superstructure design checks for precast I-girder and precast U-girder bridges have been implemented according to the BS 5400 British code.

CSiBridge 20.0.0 Enhancements Bridge Design 1

Bridge superstructure design checks for concrete slab bridges have been implemented according to the AASHTO LRFD code.

CSiBridge 20.0.0 Enhancements Bridge Design 2

Bridge superstructure design and rating of steel I-girder bridges now considers local girder effects when the bridge object is updated as a spine model.

CSiBridge 20.0.0 Enhancements Bridge Design 3

Superstructure design of concrete box-girder bridges according to AASHTO LRFD now offers the Modified Compression Field Theory (MCFT) method, including torsion, for performing shear design according to AASHTO 5.8.3.4.2.

Analysis

CSiBridge 20.0.0 Enhancements Analysis

The effect of reinforcing steel on the axial creep and shrinkage behavior of concrete in columns and walls is now included in the time dependent staged-construction analysis.

CSiBridge 20.0.0 Enhancements Analysis 1

A pure event-to-event option has been added for nonlinear static analysis.

Loading

CSiBridge 20.0.0 Enhancements Loading

The transverse position of vehicle lanes has been automated for influence-based moving load analysis using floating lane sets.

Tools

CSiBridge 20.0.0 Enhancements Drafting

Measurements

On-screen measuring tools available for measuring length, area, and angles.

19.2.0 | 19.2.1|19.2.2

Released 13-Dec-2017

Release Notes

19.1.0

Released 14-Mar-2017

Release Notes

Analysis

CSiBridge 2017 19.1.0 Enhancements Analysis

Convergence behavior of the friction-pendulum and triple-pendulum isolator link elements has been enhanced.

Output and Display

CSiBridge 2017 19.1.0 Enhancements Results Display & Output

The performance of the Bridge Object Response Display form has been enhanced when plotting previously viewed results.

CSiBridge 2017 19.1.0 Enhancements Results Display & Output 1

A detailed superstructure design output report for AASHTO steel I-girder strength design has been added.

Design

CSiBridge 2017 19.1.0 Enhancements Bridge Design

Bridge Superstructure Design

Bridge superstructure design for concrete slab deck sections per Eurocode has been added, including stress, flexural strength, shear strength, and crack checks.

Modeling

CSiBridge 2017 19.1.0 Enhancements Modeling

Moment & Shear Releases

Moment and shear releases can now be assigned to the edges of shell-type area objects.

CSiBridge 2017 19.1.0 Enhancements Modeling 1

Time-dependent material behavior now available per Eurocode 2-2004, AS 3600-2009, NZS 3101-2006, JTG D62-2004 codes and the GL2000 model. This includes creep and shrinkage strain as well as age-dependent stiffness.

CSiBridge 2017 19.1.0 Enhancements Modeling 2

Vietnamese Material Libraries

Vietnamese concrete and rebar material libraries now available.

User Interface

CSiBridge 2017 19.1.0 Enhancements Graphical User Interface

DirectX

DirectX graphics has been enhanced for quality and speed.

19.0.0

Released 18-Nov-2016

Release Notes

User Interface

CSiBridge 2017 19.0.0 Enhancements Graphical User Interface 1

Several edit menu forms enhanced to allow them to remain open for repetitive use with an apply button.

Parametric Bridge Modeling

CSiBridge 2017 19.0.0 Enhancements Bridge Modeler

Girder-Only Section Cuts

Girder-only section cuts implemented for steel I-girder bridge sections to capture changes in girder sections, staggered diaphragms, and splice locations in individual girders. This also improves the design and rating of steel I-girder sections by better accounting for the controlling section within each panel.

CSiBridge 2017 19.0.0 Enhancements Bridge Modeler 1

Linked Model

A new action Clear and Create Linked Model added to the Action dropdown list in Update Bridge Structural Model form. Once selected, the previous program-generated linked model will be cleared (and cleaned) first and a new linked model created.

Modeling

CSiBridge 2017 19.0.0 Enhancements Modeling

Hysteresis Models

New and enhanced hysteresis models for nonlinear materials, hinges, and links have been added.

CSiBridge 2017 19.0.0 Enhancements Modeling 1

PMM Hinges

A new parametric P-M2-M3 frame hinge has been implemented for use with performance-based design and other types of nonlinear analysis

Analysis

CSiBridge 2017 19.0.0 Enhancements Analysis

Energy Plots

Step-by-step energy plots available for nonlinear direct-integration time-history load cases and for nonlinear static/staged-construction load cases.

CSiBridge 2017 19.0.0 Enhancements Analysis 1

Nonlinear Hinges

Model frame nonlinear hinges as links, allowing for use of nonlinear modal time-history analysis (FNA) for faster analysis.

CSiBridge 2017 19.0.0 Enhancements Analysis 2

Size of the saved analysis results files is reduced for multi-step nonlinear static and nonlinear direct-integration time-history load cases.

Design

CSiBridge 2017 19.0.0 Enhancements Section Designer

Import Geometry

Import geometry from a DXF file into Section Designer.
